anixter#A140-0179#6-192038-6
| Description: | Specification DescriptionIndustry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant |
| Transit Time: | Transit time is 15 business days in the US |
| NCNR: | No |
| Specification Sheet: | View Document |
| Manufacturer: | TE-ENERGY |
Specification Description
Industry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant
Industry Standards.Lead Free Solder Processes: Not relevant for lead free process
Product Type Features.Gender: Female
Electrical Characteristics.Number of Louvers: 22
Body Features.Band Material: Beryllium Copper
Body Features.Preformed: Yes
Body Features.Product Name: LAIII
Body Features.Form Type: Bridge
Body Features.Band Length (mm [in]): 11.90 [0.470]
Body Features.Material Thickness (mm [in]): 0.203 [0.008]
Termination Features.Pin Diameter (mm [in]): 8.00 [0.315]
Body Features.Band Plating: Gold
Conditions for Usage.Suggested Current Limit (A): 185
Product Type Features.Termination Method to Wire/Cable: Crimp
| Negotiable | Yes |
|---|---|
| Manufacturer | TE-ENERGY |
| Specification Sheet | https://objects.eanixter.com/PD560588.PDF |
