| Description: | DescriptionThe Berk-Tek LANmark-6 features a reduced diameter compared to other category 6 UTP cables. This is an ANSI/TIA/EIA category 6 verified cable, constructed without the center spline for easy installation and termination. LANmark-6 is capable of transmitting applications such as 1000BASE-T. It is ideal for network applications that extend to 250 MHz. LANmark-6 is available in both CMP and CMR and conforms to ANSI/TIA/EIA 568-B.2-1 Category 6 and ISO/IEC 11801 2nd Edition Class E Category 6 requirements. Features
Tech InfoUL 444, ANSI/TIA-568-C.2, ISO/IEC 11801 |
| Transit Time: | Transit time is 15 business days in the US |
| NCNR: | No |
| Specification Sheet: | View Document |
| Manufacturer: | BERK-TEK |
Description
The Berk-Tek LANmark-6 features a reduced diameter compared to other category 6 UTP cables. This is an ANSI/TIA/EIA category 6 verified cable, constructed without the center spline for easy installation and termination. LANmark-6 is capable of transmitting applications such as 1000BASE-T. It is ideal for network applications that extend to 250 MHz. LANmark-6 is available in both CMP and CMR and conforms to ANSI/TIA/EIA 568-B.2-1 Category 6 and ISO/IEC 11801 2nd Edition Class E Category 6 requirements.
Features
- Inexpensive Compact Design
- Characterized to 500 MHz, 250 MHz Greater than the Standard
- Delivered in Compact, Strong, Easy to Identify Boxes
- Provides Category 6 Performance
- Cost Effective Category 6 Solution
- Provides Additional Usable Bandwidth Requi for Future Applications
- Superior Box Design Allows Cable to Be Pulled Easily from the Box with Minimum Kinking
- Compact Box Design Takes up Less Shelf Space
- Clearly Identified Packaging Eliminates Potential Confusion
Tech Info
UL 444, ANSI/TIA-568-C.2, ISO/IEC 11801
| Negotiable | Yes |
|---|---|
| Manufacturer | BERK-TEK |
| Specification Sheet | https://objects.eanixter.com/PD314033.PDF |
